Parameter |
Content |
|
Sample Type |
Whole blood, serum, plasma, throat swab, urine, feces |
|
Volume Capacity |
30 ~ 1000ul |
|
Sample Quantity |
1 ~ 32 samples |
|
Magnetic Bead Recovery Rate |
> 99% |
|
Processing Time |
Nucleic acid extraction of 32 samples in 10 minutes |
|
Inter-well Purification Variation |
CV < 3% |
|
Plate Type |
96 -well deep-well plate |
|
Preheating Function |
With preheating function, fast heating speed |
|
Working Noise |
Noise ≤ 50db |
|
Mixing |
Multi-speed adjustable |
|
Heating Temp. |
roomtemp. ~ 120℃ |
|
Display |
10-inch color touch screen |
|
Program settings |
USB flash drive importable program |
|
> 500 |
|
|
Data Storage |
|
|
Contamination Control |
HEPA sterilization,UV light,Back fan exhaust |
|
Operation |
Run the program by scanning mode, list mode, shortcut mode, and view mode. |
|
Operating Environment |
Temperature 5 ~ 40 ℃, humidity ≤ 80% |
|
Dimension |
400mm*400mm*450mm, |
|
Weight |
35kg |

Rapid extraction: Nucleic acid extraction can be completed in as little as 10 minutes.
Fully automated and high throughput: Nucleic acid extraction is fully automated, with high sample throughput, especially suitable for testing units
Stable machine operation and accurate test results.
Intelligent operation: equipped with power-on self-test program, power failure protection, precise temperature control, high temperature alarm,
Antipollution measures: the use of deep-well plates, strict control of contamination between the holes, equipped with ultraviolet disinfection lamp,
